KolorPen® developed the first and only revolutionary noninvasive way of delivering micro-droplets into the skin using Piezoelectric Technology. KolorPen’s device takes the liquid and breaks it down into micro-droplets (hundreds of nano liters) which are injected into the skin. As a result, there is no pain, no bleeding, no contamination, no healing period, no downtime, no skin injury, no epidermal damage, and with significant reduction in treatment and recovery time. Our Piezoelectric Technology is the perfect solution for a wide array of aesthetic procedures.
Several devices have been developed to deliver the liquid without a needle, by pushing a
high velocity liquid stream. Unfortunately, all these devices lack a major required element
control. KolorPen device controls the number of micro-droplets, the penetration depth, and
the droplets repetition rate (Hz).
The operation is controlled through a wireless tablet and recorded on a cloud-based system.
KolorPen system authenticate the injectables, so only approved liquids can be used,
allowing multiple business models.
KolorPen® device generate a fine stream of micro-droplets that is forced through a specially designed nozzle. The velocity of the stream enables the micro-droplets to penetrate the tissue to the required depth. The micro-droplets insertion is achieved using energy generated by a Piezoelectric Technology that creates a micro-droplets jet with a speed of up to 350 m/sec. and a diameter of 100 microns. Sub-dermal penetration achieved is over 6,000 μm, well
above that needed for the target applications.
The penetration depth is regulated by
controlling the applied power and
the size of the micro-droplets by
the proprietary embedded
KolorPen Technology eliminates The Use of Unapproved liquid. The liquids used by the KolorPen device are protected
by a proprietary QR code so that only liquids carrying the
KolorPen QR approved code can be used.
KolorPen provides the ideal technology for subcutaneous treatment requirements: non-invasive, painless, safer, shorter treatment time, no epidermal damage, and almost zero recovery times. An additional important application is by applying the active ingredient on the skin and using liquid droplets to push it into the dermis.
KolorPen patented Piezoelectric Technology advantage is its ability to deliver micro-droplets exactly into the affected skin area with accuracy and full control of micro-droplets depth and volume.
By injecting Non-Invasive, No-Touch, Needle-Free micro-droplet compositions to the skin, KolorPen Piezoelectric Technology provides an innovative and unique solution for treatments like medical aesthetics, skin diseases, dental medicine, psoriasis, acne, alopecia, dental nerve anesthesia, skin rejuvenation, Microneedling, Collagen buildup, and skin remodeling. Some examples for composition injections are: Sculptra, Radiesse Calcium hydroxylapatite, Paromomycin, Minoxidil and more.
Eyelids Raising (injections)
Spider Veins (Sclerotherapy)
Dental Application – Local Anesthesia
Clinical studies have shown that heat trauma creates ongoing Collagen buildup.
The subcutaneous heating techniques available today are Laser and RF, but none of them can insert hot active composition liquid into the skin. KolorPen warms the skin allowing collagen to build and provides the therapeutic effect of the liquid inserted. KolorPen patented piezoelectric technology is the only one that performs this combined therapeutic effect by inserting hot micro-droplets into the skin and works on all skin colors.
By using the KolorPen digital settings, the micro-droplets are delivered at the desired depth, precise temperature, and exact amount. Treatment with KolorPen system causes significantly less discomfort and has lower complications than the other methods
Using the KolorPen pen, hot water micro-droplets were injected into a pig skin at a temperature of 60 degrees Celsius, through a nozzle of 100 microns and at a rate of 50 drops per second. The histological picture below shows the action of the hot micro-droplets in the marked area.
The KolorPen system offers a no-needle alternative to micro-needling.
The KolorPens system is shooting micro-droplets on the cream applied on the skin, penetrating it to the required depth in a precise and comfortable way to the patient. It increases material absorption into the skin without wounding the skin or triggering inflammation.
KolorPen system works on the same principle as micro-needling or CIT (collagen induction therapy) but without the use of needles, creating micro channels into the skin to deliver product ingredients, that would otherwise struggle to bypass the skins.
Above are the results of a histological reports of using the KolorPen’s technology for applying blue cream on the pig skin.
The cream penetrated to the required depth with no epidermal damage.
KolorPen technique can be used for any insertion of high viscosity serum and
cream for Skin Rejuvenation, Micro-Needling, Facial Skin Massage and more…
KolorPen® is particularly suited for micro-pigmentation procedures. It provides very accurate results, and the color lines are thin, and very precise. Permanent makeup, permanent cosmetics, or cosmetic tattooing can be done easily with KolorPen device in places like eyebrows, eyelashes, eyeliner, and lips. It’s also used to cover scars and restore colors to areas of skin that have lost colors. KolorPen also can be used for inserting active ingredients (like serums), without the need to use needles, by applying the ingredient on the skin and using liquid micro-droplets to push it into the dermis. KolorPen® is particularly suited for micro pigmentation procedures. It provides very accurate results – the color lines are thin, and very precise.KolorPen also can be used for inserting active ingredients, like serums, without the need to use needles, by applying the ingredient on the skin and using liquid droplets to push it into the dermis.
Tattoo done by Shahar Navot with KolorPen System
Needless drug delivery
Needless drug delivery
Tattoo done by Shahar Navot with KolorPen System
Work done on pig skin with the KolorPen system and histological reports issued by the Tissue Research Institute of Haemek Hospital shows that there is no epidermal damage, and that the penetration depth is about 1,000μm, the droplet spread is about 250μm, and the point of penetration is about 35 μm
Mr. Gamliel is the founder, inventor and the CEO of KolorPen, Mr. Gamliel has over 35 years of experience in the Hi-Tech industry including products developing, worldwide marketing activities, and strategic alliance. Mr. Gamliel was the Founder, Chairman and President of Gambit Computer Communications Ltd. A hi-tech company that developed Networking products for corporate applications.
Mr. Gamliel led Gambit through a series of strategic and OEM agreements including the strategic alliance with Memorex Telex, Inc. a worldwide leader in the IBM compatible market. Under Mr. Gamliel’s management, Gambit went public in the Tel-Aviv Stock Exchange. Mr. Gamliel holds B. Sc. in Computers & Electronic Engineering from the Technion, Haifa Israel.
Dr. Weissman educated as a physicist, and obtained his Ph.D Degree from Tel Aviv University (Israel) at 1980. Dr. Weissman scientific career lasted for about 30 years, and was devoted to research in quantum mechanics and optics. During this period Dr. Weissman published over 30 papers in the scientific literature and a scientific books. Dr. Weissman scientific activity gave way to technological R&D, and his publications were replaced by patents.
Dr. Weissman skills include creativity and initiative, Innovations, excellent capability in fast and efficient proof of concept and feasibility study, ability to analyze and design complex interdisciplinary systems.
Ina holds a BA in arts from the Israeli Technion and has MPMU multiple certifications from academics worldwide.
Mr. Erel is an experienced business manager, proven entrepreneur and International financial consultant. Mr. Erel has established the leading Infrastructure Finance consulting platform in Israel and had a long career as investment banker.
Mr. Erel served on the Board of directors in several companies, including a leading Israeli Asset Management firm, and the trading subsidiary of a large Industrial multinational UK group. Mr. Erel holds a B.Sc. in Industrial Engineering & Management from the Technicon in Haifa, Israel and an MBA from INSEAD, France.
Mr. Meir Yaniv brings more than 40 years of industry experience, deep expertise and knowledge and executive management experience in building businesses in US, Europe, Asia Pacific and Israel. Meir currently acts as a business development advisor to start-up companies in Israel and abroad.
With a strong technical background and an entrepreneurship impetus, Meir founded and managed several companies and was involved in their worldwide development. In the latter part of Meir career, he was responsible, as a C level executive, for building global sales and support networks for US companies and established and managed subsidiaries in the major Europe and Asia Pacific markets. Currently, Meir is active and serves on the Board of Directors of several companies that have developed medical and cosmetics related products. Meir holds a BSc and MSc in Sciences from the Technion in Haifa.
Shony has more than 15 years of experience in board design and projects management, Shony is considered as hardware designer and expert. Shony worked as senior developer engineer in IAI and Elbit and as a project manager in CI-systems and startup companies, Shony has deep knowledge in electronic systems development, starting from the RFQ and ending up with a fully functional and regulated product. Some of the applications comply with the demanding military environmental, EMC and safety specifications, others developed for the harsh industry environment and others designed for commercial use.
Shony experience include iMX6, ARM, MSP430, AtMega, DSP, OMAP, C++ drivers, Linux, WIN-CE, Windows OS, WiFi, Bluetooth, and PID algorithm.
Meir is an Israeli serial entrepreneur and investor focused on disruptive technologies in the global automotive and smart mobility spaces.
As a founding member of the smart mobility industry in Israel, Meir has a deep understanding of smart mobility ventures and innovation partnerships. He is focus on bringing innovative technologies to global automotive manufacturers.
Meir holds a B.Sc. from the Technion – Israel Institute of Technology, and is a graduate of INSEAD and HBS. He is an active member of YPO and the founder of the YPO Automotive Network.
Aibrahem as B.Sc. Physics and Biomedical Engineering. is a senior developer with extensive experience in the field of software development and complex communication applications. Aibrahem’s experience and knowledge include PythonAndroid, XML, HTML, C #, KOTLIN, Swift, Java Scrip, Objective C, Java, and also include Integrated development environment such Xcode languages, IntelliJ Idea, Visual Studio, Eclipse and full control of operating systems like MAC-OS, Windows, Linux.
Aibrahem is responsible for developing the hardware and the software architecture of the company’s products in a way that will always be at the frontend of the global technology.
Lilya, is a senior chemical engineer with extensive experience in developing pigments for various industries applications including the medical aesthetics industry and has experience in diagnosing, analyzing, and monitoring various toxins parameters and has an experience of international standards protocols.
Lilya is currently developing all the process to create and produce the set of pigments for permanent makeup that contains special properties related to viscosity, flow, pigment size and other properties.
